Cobot Laser Welding Cell Starting from $25.000
The Cobot System is an ideal solution for increasing production efficiency by automating welding processes in industrial applications.
Automotive Industry
Vehicle parts, fasteners, chassis components
Furniture & Accessories
Metal frames, chair legs, connection points
Construction & Building
Anchors, plugs, panels, steel profiles
Electrical & Energy
Cable trays, electrical panels, solar energy carriers
Machinery Manufacturing
Component protection, connection modules
Agricultural Equipment
Agricultural machinery parts, metal fittings
The Cobot System is an ideal solution for increasing production efficiency by automating welding processes in industrial applications. With high-precision and repeatable motion capability, it can perform fast and reliable welding operations on various metals. Thanks to its compact size with a large working envelope and a wheel structure integrated into the entire system, it can be positioned flexibly in your workplace and moved with ease.
With the cobot's six-axis motion capability and integrated safety systems, human-robot collaboration becomes safer. These features reduce operators' workload in repetitive and precise welding tasks, allowing them to focus on more complex duties. Featuring a wide operating temperature range of 0°C–50°C and IP54/IP67 protection classes, the LaserCube & Cobot System delivers high performance even in harsh industrial environments.
Technical Specifications
| Payload Capacity | 10KG |
|---|---|
| Maximum Reach Radius | 1455mm |
| Cobot Body Weight | 55KG |
| Maximum Speed | 1,500mm/s |
| Repeatability | 0.05mm |
| Axes | 6 Axes |
| Power Supply | 220 VAC - 50/60HZ |
| Power Consumption | 400W |
| Operating Temperature Range | 0°C - 50°C |
| Protection Class (IP) | IP54 / IP67 |
